Computational design of high performance hybrid perovskite on silicon tandem solar cells - Université de Rennes
Pré-Publication, Document De Travail Année : 2016

Computational design of high performance hybrid perovskite on silicon tandem solar cells

Claudine Katan

Résumé

In this study, the optoelectronic properties of a monolithically integrated series-connected tandem solar cell are simulated. Following the large success of hybrid organic-inorganic perovskites, which have recently demonstrated large efficiencies with low production costs, we examine the possibility of using the same perovskites as absorbers in a tandem solar cell. The cell consists in a methylammonium mixed bromide-iodide lead perovskite, CH3NH3PbI3(1-x)Br3x (0 \textless x \textless 1), top sub-cell and a single-crystalline silicon bottom sub-cell. A Si-based tunnel junction connects the two sub-cells. Numerical simulations are based on a one-dimensional numerical drift-diffusion model. It is shown that a top cell absorbing material with 20% of bromide and a thickness in the 300-400 nm range affords current matching with the silicon bottom cell. Good interconnection between single cells is ensured by standard n and p doping of the silicon at 5.10^19cm-3 in the tunnel junction. A maximum efficiency of 27% is predicted for the tandem cell, exceeding the efficiencies of stand-alone silicon (17.3%) and perovskite cells (17.9%) taken for our simulations, and more importantly, that of the record crystalline Si cells
Fichier principal
Vignette du fichier
1509.01612.pdf (1.44 Mo) Télécharger le fichier
Origine Fichiers produits par l'(les) auteur(s)
Loading...

Dates et versions

hal-01275497 , version 1 (17-02-2016)

Identifiants

Citer

Alain Rolland, L. Pedesseau, Alexandre Beck, Mikael Kepenekian, Claudine Katan, et al.. Computational design of high performance hybrid perovskite on silicon tandem solar cells. 2016. ⟨hal-01275497⟩
